תיאור
Performance
• Membrane keypad with simple menus for intuitive use
• Push button controls are conveniently located to ensure that temperatures can be recorded without looking away from the sample
• Digital microprocessor with ±1°C resolution provides fast warm-up and accurate temperature control
• Samples in 3 capillary tubes may be viewed simultaneously.
• Push button controls are conveniently located to ensure that temperatures can be recorded without looking away from the sample
• Digital microprocessor with ±1°C resolution provides fast warm-up and accurate temperature control
• Samples in 3 capillary tubes may be viewed simultaneously.
Safety and convenience
• 3 Audible beeps indicate that the oven temperature is stable and ready for sample
• Adjustable arm with viewing magnifier can be folded away into the unit
• Adjustable object lens for sharp focus
• Rotating viewing head and safety eye piece to protect against glare and hot zone
• Integral light and wide angle 8X viewing magnifier enhance sample observation, so that all 3 samples can be viewed without eye strain
• Units can be calibrated by the user on their site or by the manufacturer/service organisation. If calibrated by the user, a calibration kit is required
• Improved calibration procedure using a calibration key
• Adjustable arm with viewing magnifier can be folded away into the unit
• Adjustable object lens for sharp focus
• Rotating viewing head and safety eye piece to protect against glare and hot zone
• Integral light and wide angle 8X viewing magnifier enhance sample observation, so that all 3 samples can be viewed without eye strain
• Units can be calibrated by the user on their site or by the manufacturer/service organisation. If calibrated by the user, a calibration kit is required
• Improved calibration procedure using a calibration key
Technical specification
| Mel-Temp® Model | 1101D |
|---|---|
| Temperature range | Ambient to 400°C |
| Fixed temperature ramp rate | 1°C per minute |
| Fast temperature ramp rate | 10°C per minute |
| Temperature resolution | ± 1°C |
| Accuracy | ± 1 |
| Temperature sensor | PT100 Platinum Resistance |
| 40mm diameter removable lens | 8X magnification with adjustable focus |
| Display | 2 rows of 12 characters with backlit LCD |
| Colour | Black |
| Processor | 32-bit processor |
| Keypad | 13-key membrane |
| Capillary tubes | Accommodates 3 tubes up to 2mm OD |
| Tube Guide | Removal for cleaning and use of cold finger |
| LED | White LED illuminated oven |
| Melt memory | 4 x 1 Melt memory capacity |
| Power requirements | 100-240V, 50 / 60Hz, 15DC, 45W |
| Dimensions (d x w x h) | 35.5 x 20 x 8cm |
| Weight | 2.5kg |
