The most accurate refractometer in the world is now even more stylish, smart, and functional.
Featuring intuitive touch screen technology, the new RX-i series makes navigation and selection a breeze.
The RX-5000i-Plus measures with the same accuracy level as the RX-5000α-Plus – ±0.010% Brix and ±0.00002 nD.
The RX-i series come with newly added functions, such as USB flash drive and self-diagnosis capability.
| Scale | Refractive index Brix |
|---|---|
| Measurement Range | Refractive index (nD) : 1.32422 to 1.58000 Brix : 0.000 to 100.000% (5 to 75°C ATC) |
| Resolution | Refractive index (nD) : 0.00001 Brix : 0.005% Temperature: 0.01°C |
| Measurement Accuracy | Refractive index (nD) : ±0.00002 Brix : ±0.010% * When measuring a standard sucrose solution of up to 50% Brix or standard refractive index solution in MODE-1 at 20°C |
| Repeatability | Refractive index (nD) : ±0.00001 Brix : ±0.010% * When measuring a standard sucrose solution of up to 50% Brix or standard refractive index solution in MODE-1 at 20°C |
| Temperature control range | 5.00 to 75.00°C (No lower than 10°C below the ambient temperature and no higher than 55°C above the ambient temperature) |
| Power Supply | AC100V to 240V, 50/60Hz |
| Dimensions & Weight | 37×26×14cm, 6.6kg (Main Unit only) |
| Power consumption | 90VA |
| Mode | MODE-1:Displays the measurement value once the sample reaches the target temperature.MODE-2:Measures refractive index and temperature at fixed intervals and displays the estimated measurement value at the target temperature.MODE-3:The thermo-module can be turn off. Without temperature control, the measurement value is displayed in 4 seconds after the START key is pressed.
MODE-S:Displays the measurement value once a certain level of sample stability is achieved. |
| Output terminals | • Printer (for ATAGO digital printers) • Computer -USB |
