Your Advantages
- Heat build-up and blow out tests according to Goodrich (DIN 53 533, ASTM D 623, ISO 4666/3,ISO 4666/4, BS 903 part A50 and JIS K 6265)
- Goodrich flexometer tests
- Static: strain or stress controlled load mode available
- Dynamic: strain or stress controlled load mode available
- Wide frequency range (option)
- Wide temperature range (option)
- Automatic Sample Changer (ASC) for fully automatic testing (24h) (option)
- Simultaneous measurement of the visco-elastic properties (option)
- Visco-elastic properties in DMTS/DMA mode (option)
- Hysteresis analysis (option)
- Pulse load mode available (option)
Key Technical Data
(subject to change)
Frequency range:
30 Hz
0.5 up to 50 Hz continuously (option, depending on model)
Static Strain Range:
up to 60 mm
Dynamic Strain Range:
± 1.5 mm
(optional up to ± 10 mm)
Force Range:
up to 2500 N
Temperature Range:
RT up to 300°C
Test Specimen size:
Diameter: up to 30 mm (optional < 40 mm), depending on model
Length: 25 mm
